LEONDARX / Door Station
2-wire Smart Video Villa Intercom
A 2-wire villa door station for entrance communication. Confirm the compatible indoor equipment, supply and access interface.
At the entrance. Built for the access workflow.
Explore the application, daily use and installation requirements for this model.
A clear point of arrival.
The outdoor station is the visitor-facing part of an intercom installation. Match the call workflow and access interface to the building.
- The JS-D2 home access control terminal adopts aluminum alloy housing, equipped with a household button and a built-in 2-megapixel wide dynamic CMOS camera.
- It supports image correction, video recording and message functions, and can control multiple door locks.
Communication at the door.
Review the documented call, camera and access functions for this version. The indoor answer point and connected equipment are specified as part of the system.
- With multi-language voice prompts and embedded Linux system, it provides a convenient and stable user experience.
Specify the entrance together.
Confirm the mounting position, power arrangement, cable route and release interface before installation.
- Housing Material: Explosion-proof aluminum alloy, 1 household button, nameplate/owner name placeable on button left
- Door Lock Control: 1-3 relay outputs, controls 1-3 door locks
- Power Consumption: ≤2.5W in standby mode ≤5.5W during operation
The details behind the selection.
Specifications apply to this model. Confirm the hardware revision, optional functions and installation requirements before ordering.
- Housing Material
- Explosion-proof aluminum alloy, 1 household button, nameplate/owner name placeable on button left
- Camera
- 2-megapixel WDR CMOS, supports image correction
- Video Encoding
- H.264/H.265, 720P/1080P (depends on display resolution)
- Door Lock Control
- 1-3 relay outputs, controls 1-3 door locks
- Power Consumption
- ≤2.5W in standby mode ≤5.5W during operation
- Voice Prompt
- Multi-language support (Chinese, Russian, English, Portuguese, Persian)
- Additional Functions
- Image capture, voice message, video message
- Operating System
- Embedded Linux system
- Color
- Space Gray
COMPLIANCE DOCUMENTATION
Check the evidence for your market.
Request documents that identify the exact model and test scope. Published manufacturer material is a reference; confirm applicability to your destination market and ordered configuration.
Request compliance documents ↗2-wire Smart Video Villa Intercom
Confirm applicable reports and declaration documents with the project team.Before you specify.
Installation and ordering questions for this model.
What should I confirm before ordering this model?+
Confirm the hardware revision and installation configuration for 2-wire Smart Video Villa Intercom. Published details include Housing Material: Explosion-proof aluminum alloy, 1 household button, nameplate/owner name placeable on button left; Door Lock Control: 1-3 relay outputs, controls 1-3 door locks; Power Consumption: ≤2.5W in standby mode ≤5.5W during operation. Use the original model material below and request the matching technical sheet.
Can it be used with the existing installation?+
Confirm the existing cabling, supply, topology and communication interfaces against the selected model. Connected devices and optional gateways must be checked as a complete system.
Which documents are available for project review?+
Original manufacturer images and model detail sheets are retained below. Request current installation instructions, version-specific specifications and any applicable compliance documents for your market and ordered configuration.
Original model material.
Manufacturer views, drawings and original detail sheets remain available for a technical review.
View manufacturer images & drawings+
Original manufacturer description+
Original source material for reference. General service terms and version-dependent claims require confirmation for your order.
The JS-D2 home access control terminal adopts explosion-proof aluminum alloy housing, equipped with a household button and a built-in 2-megapixel wide dynamic CMOS camera. It supports image correction, video recording and message functions, and can control multiple door locks. With multi-language voice prompts and embedded Linux system, it provides a convenient and stable user experience.
Start with the installation.
Share the door or room layout, target market, quantities and integration requirements. We can help define the model configuration.
